Hybrid Invertors DEYE LV

///Hybrid Invertors DEYE LV

DEYE single-phase hybrid inverters

SUN 3.6/6K-SG hybrid inverters are suitable for residential and light commercial use, maximizing your solar self-consumption rate and increasing your energy resilience. During the day, the photovoltaic system generates electricity, which will initially be provided to the loads. The excess energy will then charge the battery. Finally, the stored energy can be released when the loads demand it. The battery can also be charged by the diesel generator to provide continuous power in the event of a power outage.

Ability to work in On-grid and OFF-grid modes.

Full power operation in case of mains failure in UPS mode.

Properties and characteristics

  • High efficiency (up to 97.6%)
  • Wide PV voltage range, longer working time, higher PV generation energy.
  • Color touchscreen LCD display, IP65 protection class
  • DC connection and AC connection possible for retrofitting existing solar systems.
  • Maximum 16 units in parallel, on-grid and off-grid functionality;
  • Support for multiple batteries in parallel.
  • Maximum charge and discharge current 190A
  • 6 battery charge/discharge time periods
  • Supports energy storage from diesel/gasoline generator
  • 5 years warranty, authorized service for Bulgaria

    Three-phase hybrid inverters DEYE LV

    SUN 5/6/8/10/12K-SG are three-phase hybrid inverters working with low-voltage 48V batteries, guaranteeing a safe and reliable system. Support three-phase unbalanced output, expanding application scenarios. Equipped with CAN port (x2) BMS and parallel, x1 RS485 port for BMS, x1 RS232 port for remote control, x1 DRM port, making the system intelligent and flexible.

    Suitable for photovoltaic systems in large households and industrial sites with a three-phase network.

    During the day, the photovoltaic system generates electricity, which will initially be provided to the loads. The excess energy will then charge the battery. Finally, the stored energy can be released when the loads demand it. The battery can also be charged by the diesel generator to provide continuous power in the event of a power outage.

    Full power operation in case of mains failure in UPS mode.

    Possibility of returning excess energy to the grid.

    Properties and characteristics

    • High efficiency (up to 97.6%)
    • Color touchscreen LCD display, IP65 protection class
    • Wide PV voltage range, longer working time, higher PV generation energy.
    • 100% unbalanced output on each phase; Max. power up to 50% above rated power
    • DC connection and AC connection possible for retrofitting existing solar systems.
    • Maximum 10 units in parallel, on-grid and off-grid functionality;
    • Support for multiple batteries in parallel.
    • Maximum charge and discharge current 240A
    • 48V low voltage battery, isolated transformer
    • 6 battery charge/discharge time periods
    • Supports energy storage from diesel/gasoline generator
    • 5 years warranty, authorized service for Bulgaria
